Ball Heads

Gitzo ball heads, with smooth movements and precise control, enable photographers to move fast and lock the head whenever necessary. Gitzo is famous for its carbon tripods range and the centre ball heads are their perfect match. The Gitzo ball heads are available in three sizes and are perfect in combination with the Mountaineer and Traveler tripods. Innovation in systems and materials allows for exceptional locking power and ultra-smooth high precision movements.

Gitzo Heads Ball Heads

Ball Heads

Gitzo ball heads, with smooth movements and precise control, enable photographers to move fast and lock the head whenever necessary. Gitzo is famous for its carbon tripods range and the centre ball heads are their perfect match. The Gitzo ball heads are available in three sizes and are perfect in combination with the Mountaineer and Traveler tripods. Innovation in systems and materials allows for exceptional locking power and ultra-smooth high precision movements.

Gitzo Gitzo tripod kit Mountaineer, series 1, 4 sections GK1542-82QD GH1382QD

Gitzo center ball head, quick release, series 1

Weight 0.5 kg
Base Diameter 42 mm
Material Aluminium
Front Tilt -90° / +40°
Safety Payload UNI/PdR 105:2021 14 kg
Bubble Spirit Level (No.) 1
Plate Type GS5370SD
Certifications none
Colour Noir Decor
Base Type 40 mm
Ball Locking Yes
Top Attachment 1/4″ screw
Easy Link No
Friction Control Yes
Head Type Ball Head
Independent Pan Lock Yes
Lateral Tilt -90° / +40°
Maximum Working Temperature 70 °C
Minimum Working Temperature -30 °C
Pan Bar Included No
Pan Drag NONE
Panoramic Rotation 360 °
Quick Release Yes
Tilt Drag NONE
Working Height 11.2 cm
Gitzo Gitzo center ball head Traveler, quick release, series 1 GH1382TQD GH1382TQD

Gitzo center ball head Traveler, quick release, series 1

Weight 0.39 kg
Base Diameter 35 mm
Material Aluminium
Front Tilt -90° / +40°
Safety Payload UNI/PdR 105:2021 11 kg
Bubble Spirit Level (No.) 1
Plate Type GS5370SD
Certifications none
Colour Noir Decor
Base Type 32 mm
Ball Locking Yes
Top Attachment 1/4″ screw
Easy Link No
Friction Control No
Head Type Ball Head
Independent Pan Lock Yes
Independent Tilt Lock yes
Lateral Tilt -90° / +40°
Maximum Working Temperature 70 °C
Minimum Working Temperature -30 °C
Pan Bar Included No
Pan Drag NONE
Panoramic Rotation 360 ° °
Quick Release Yes
Tilt Drag NONE
Working Height 10.4 cm
GH2750QR GH2750QR

Gitzo off centre ball head, quick release, series 2

Weight 0.55 kg
Base Diameter 60 mm
Material Magnesium
Front Tilt -180° / +180°
Safety Payload UNI/PdR 105:2021 5 kg
Plate Type quick release - with 1/4″ screw
Colour Noir Decor
Base Type 25 mm
Ball Locking Yes
Top Attachment 1/4″ screw
Easy Link No
Friction Control Yes
Head Type Ball Head
Independent Pan Lock Yes
Independent Tilt Lock Yes
Lateral Tilt 0° / +90°
Maximum Working Temperature 70 °C
Minimum Working Temperature -30 °C
Pan Bar Included No
Pan Drag NONE
Panoramic Rotation 360 ° °
Quick Release Yes
Series 2
Tilt Drag variable (7 steps)
Working Height 11 cm
Gitzo Gitzo center ball head, quick release, series 3 GH3382QD GH3382QD

Gitzo center ball head, quick release, series 3

Weight 0.77 kg
Base Diameter 60 mm
Material Aluminium
Front Tilt -90° / +40°
Safety Payload UNI/PdR 105:2021 20 kg
Bubble Spirit Level (No.) 1
Plate Type GS5370D
Certifications none
Colour Noir Decor
Base Type 50 mm
Ball Locking Yes
Top Attachment 1/4″ screw
Easy Link No
Friction Control Yes
Head Type Ball Head
Independent Pan Lock Yes
Independent Tilt Lock yes
Lateral Tilt -90° / +40°
Maximum Working Temperature 70 °C
Minimum Working Temperature -30 °C
Pan Bar Included No
Pan Drag NONE
Panoramic Rotation 360 °
Quick Release Yes
Tilt Drag NONE
Working Height 12.6 cm
GH3750QR GH3750QR

Gitzo off centre head, quick release, series 3

Weight 0.79 kg
Base Diameter 70 mm
Material Magnesium
Front Tilt -180° / +180°
Safety Payload UNI/PdR 105:2021 9 kg
Bubble Spirit Level (No.) 1
Plate Type quick release - with 1/4″ screw
Colour Noir Decor
Base Type 32 mm
Ball Locking Yes
Top Attachment 1/4″ screw
Friction Control Yes
Head Type Ball Head
Independent Pan Lock Yes
Independent Tilt Lock Yes
Lateral Tilt 0° / +90°
Maximum Working Temperature 70 °C
Minimum Working Temperature -30 °C
Pan Bar Included No
Pan Drag NONE
Panoramic Rotation 360 ° °
Quick Release Yes
Series 3
Tilt Drag NONE
Working Height 13 cm
Gitzo Gitzo center ball head, quick release, series 4 GH4383LR GH4383LR

Gitzo center Ball Head, Series 4 - Lever

Weight 0.9 kg
Base Diameter 60 mm
Material Aluminium
Front Tilt -90° / +40°
Safety Payload UNI/PdR 105:2021 30 kg
Bubble Spirit Level (No.) 1
Plate Type GS5370DR
Certifications none
Colour Noir Decor
Base Type 54 mm
Ball Locking Yes
Top Attachment 1/4''
Easy Link No
Friction Control Yes
Head Type Ball Head
Independent Pan Lock Yes
Independent Tilt Lock Yes
Lateral Tilt -90° / +40°
Maximum Working Temperature 70 °C
Minimum Working Temperature -30 °C
Pan Bar Included No
Pan Drag fluid cartridge with fixed drag
Panoramic Rotation 360 °
Quick Release Yes
Tilt Drag NONE
Working Height 12.5 cm
Gitzo Gitzo center Ball Head, quick release, Series 4 GH4383QD GH4383QD

Gitzo center Ball Head, Series 4 - Screw

Weight 0.9 kg
Base Diameter 60 mm
Material Aluminium
Front Tilt -90° / +40°
Safety Payload UNI/PdR 105:2021 30 kg
Bubble Spirit Level (No.) 1
Plate Type GS5370DR
Certifications none
Colour Noir Decor
Base Type 54 mm
Ball Locking Yes
Top Attachment 1/4''
Easy Link No
Friction Control Yes
Head Type Ball Head
Independent Pan Lock Yes
Independent Tilt Lock Yes
Lateral Tilt -90° / +40°
Maximum Working Temperature 70 °C
Minimum Working Temperature -30 °C
Pan Bar Included No
Pan Drag fluid cartridge with fixed drag
Panoramic Rotation 360 °
Quick Release No
Tilt Drag NONE
Working Height 12.5 cm
GH5750QR GH5750QR

Gitzo head off centre quick release, series 5

Weight 1 kg
Base Diameter 76 mm
Material Magnesium
Front Tilt -180° / +180°
Safety Payload UNI/PdR 105:2021 14 kg
Bubble Spirit Level (No.) 1
Plate Type quick release - with 1/4″ screw
Colour Noir Decor
Base Type 40 mm
Ball Locking Yes
Top Attachment 1/4″ screw
Friction Control Yes
Head Type Ball Head
Independent Pan Lock Yes
Independent Tilt Lock Yes
Lateral Tilt 0° / +90°
Maximum Working Temperature 70 °C
Minimum Working Temperature -30 °C
Pan Bar Included No
Pan Drag NONE
Panoramic Rotation 360 ° °
Quick Release Yes
Series 5
Tilt Drag NONE
Working Height 14.2 cm
Gitzo Gitzo Légende - Traveler Tripod Kit GK1545T-RTI GK1545T-RTI

Gitzo Légende - Traveler Tripod Kit

Weight 1.45 kg
Maximum Height 165 cm
Closed Length 43 cm
Head Type Ball Head
Safety Payload Weight 8 kg
Maximum Height (with Center Column Down) 141 cm
Base Diameter 42 mm
Bubble Spirit Level (No.) 1
Center Column rapid
Upper Disc Diameter 42 mm
Colour black/silver
Leg Sections 4
Top Attachment 1/4''
Easy Link No
Friction Control Yes
Front Tilt -90° / +40°
Min Height 43 cm
Independent Pan Lock YES
Ball Locking Yes
Lateral Tilt -90° / +40°
Leg Type Single
Leg Angles 25°, 70°
Leg Lock Type Twist Lock
Legs Tube Diameter 25.3, 21.7, 18.2, 14.7 mm
Material Aluminium, CarbonExact
Maximum Working Temperature 60 °C
Minimum Working Temperature -30 °C
Pan Drag NONE
Panoramic Rotation 360 °
Plate Type GS5370SDR
Quick Release No
Series 1
Tilt Drag NONE
